SNX 4210 Mini PC

Processor & Graphics

Processor Options

• Intel® Core™ Alder Lake-U

  • i3-1215U

  • i5-1235U

  • i7-1255U

• Intel® Core™ Raptor Lake-U

  • i3-1315U

  • i5-1335U

  • i7-1355U

These processors deliver an excellent balance of performance and energy efficiency for high-resolution multimedia workloads.

Graphics

• Intel® UHD Graphics (Core i3 processors)

• Intel® Iris® Xe Graphics (Core i5 & i7 processors)

• Hardware-accelerated video decoding for smooth 4K UHD playback

Memory

• 2 × SO-DIMM DDR4 slots

• Maximum supported memory: 64GB

• Ideal for demanding signage software and multi-content playback

Display Output

• 3 × HDMI 2.0b

  • Supports up to 4K @ 60Hz

• 1 × DisplayPort 1.4a

  • Supports up to 4K @ 60Hz

Supports quad-display configurations, perfect for video walls and large-format billboard control.

Storage

• 1 × M.2 2280 (SATA / NVMe SSD)

• 1 × M.2 2280 (NVMe SSD)

• High-speed storage ensures fast boot times and smooth content loading

Networking

• 2 × 2.5 Gigabit Ethernet (RJ45)

  • Intel® I225-V / I226-V controllers

• Designed for high-bandwidth media streaming and network redundancy

Wireless & Cellular Expansion

• Wi-Fi

  • M.2 2230 E-Key slot

  • Supports Wi-Fi 5 (ac) and Wi-Fi 6 / 6E (ax)

• 4G LTE

  • Mini PCIe slot for LTE module

  • Onboard SIM slot on motherboard

I/O Interfaces

Front I/O

• Power Button

• Microphone Input

• Audio Output

• 4 × USB 3.2 Gen 2

• 1 × USB Type-C

Rear I/O

• 2 × 2.5GbE LAN

• 3 × HDMI 2.0b

• 1 × DisplayPort 1.4a

• 2 × USB 2.0

Side I/O

• 2 × COM Ports

  • RS-232 / RS-485 (jumper selectable)

BIOS & System Management

• UEFI BIOS

• Wake-on-LAN

• PXE Boot

• Auto Power On after power recovery

These features support remote management and unattended operation, critical for large-scale signage deployments.

Power

• AC Input: 100–240V

• DC Output:

  • 19V / 3.42A

  • 19V / 4.74A

Mechanical Specifications

• Chassis Dimensions: 174 × 125 × 41 mm

• Material: Metal enclosure

• Designed for durability, thermal efficiency, and long service life

Mounting Support

• VESA Mount: 70 × 70 mm / 100 × 100 mm

• Suitable for behind-display, wall, or enclosure installations

Operating System Support

• Windows® 11

• Windows® 10

• Linux

Environmental Specifications

• Operating Temperature: −20°C to +55°C

• Suitable for demanding commercial and semi-industrial environments

Accessories (Included)

• AC Power Adapter

• HDMI Cable

• VESA Mount Bracket

• Wi-Fi Antennas

Packaging Information

• Net Weight: 0.98 kg / unit

• Gross Weight: 1.88 kg / unit
  (Includes PSU, VESA mount, HDMI cable, and accessories)

Carton Packaging

• 10 units per carton

• Carton Weight: 20.0 kg

• Carton Size: 53 × 23.5 × 35.5 cm

Typical Applications

• Digital billboards & LED signage

• Multi-screen video walls

• Retail & shopping mall displays

• Transportation & airport signage

• Corporate & hospitality digital signage

• Industrial HMI & information terminals
